Home > Products > NC Servo Feeding System

Products

MAC1 Series Straightener Feeder(Thickness 0.2mm〜3.0mm)
MAC1 Series Straightener Feeder(Thickness 0.2mm〜3.0mm)
Click download PDF
  • Details
  • Parameter
  • Images

Product Features :

■ MAC1/MAC1 -F handles material up to 300mm width and 3.2mm thickness.

■ This is the standard compact, high-performance straightener feeder system, and this model has been a best seller since it was put into the market.

■ Maintenance and roll cleaning is made easy by an opening at the top of the straightener.

■ Roller diameter PU plastic special treatment, to prevent the material has an indentation for sheet material special design.

Specification :

Model

MAC 1-300

MAC1-400

Stock Width(mm)

50-300

50-400

Stock Thickness(mm)

0.2-3.0

0.2-3.0

Max. Coil Weight(kg)

3000

3000

Max. Coil O.D.(mm)

1200

1200

Coil I.D.(mm)

508

508

Feed Length(mm)

~400※

〜400※

Max. Line Speed(m/min)

16-24

16-24

Work Roll Number

upper4 / lower3

upper4 / lower3

Feed Roll number

1

1

Main Motor(kw)

AC2.0

AC2.0

Mandrel Expansion

By manual (pneumatic) / hydraulic

By manual (pneumatic) / hydraulic

Reel Motor(kw)

1.5

1.5

Power (V)

3Phase 220V/380V/50HZ

3Phase 220V/380V/50HZ

Operating Air (Mpa)

0.49

0.49



 Straigtening Performance:

Stock Thickness (mm)

Stock Width (mm)

0.2

300

400

0.4

0.6

0.8

1

1.2

1.4

300

1.6

250

250

2

190

190

2.3

160

160

3

100

100
