Product Features :

■ Adopt integrated high-strength casting machine, with internal stress relief process , to guarantee long-term precision.

■ Three-circle guide pillar slider structure, adopting alloy steel bush and forced lubrication, so that thermal change can fall to the minimum and ensure high precision.

■ Dynamic equilibrium system is used to balance bent axles and offset vibration generated when slider high speed running ,  and to ensure stability of slide bottom dead center.

■ Manual mould-height adjustment is equipped with mould-height indicator and hydraulic mould locking device.

■ Human-computer interface (electronic cam + rotary encoder) operation convenient and accurate.

■ Operating functions are integrated on LCD ( Liquid Crystal Display ) , machine malfunction will be display automatically.

■ Adopt highly sensitive and reliable clutch/brake and internationally top duplex magnetic valve, to guarantee precision and safety for operation and stop of press rams.

■ With thorough electric loop design, they can be matched with various automatic devices, to conduct automatic production for reducing cost and improving efficiency.

Standard Configuration :

■ Top stop

■ Manual slider adjusting device

■ Mould-height indicator

■ Frequency converter

■ Programmable control (PLC)

■ Touch screen (pre-set pre-cut, and counter, angle indicator)

■ Encoder (electronic) reserved (2 groups)

■ Operation box

■ Air source connector

■ Mould Sticking release device

■ Main motor (adjustable speed)

■ Hydraulic -mould locking

■ Mechanical crank angle indicator

■ Forced -circulation Lubrication device

■ Tool box

■ Operating manual

■ Power socket

■ Independent electric control cabinet

Optional Configuration :

■ Anti-vibration foot

■ Feeder

■ Decoiler

■ Material oil lubricating device

■ Bottom dead center detector

■ Oil cooler

■ Mould light

■ Air-blast device
